YZ-inspired handling and looks, and a clockwork reliable 223cc air-cooled, SOHC four-stroke make the TT-R230 a great choice for beginner and intermediate riders.
A competition-style flat seat/tank junction makes for great rider mobility while the push-button start is a no brainer. A low seat height on top of a long-travel suspension and generous ground clearance make this a serious trail bike that's accessible to wide range of riders.
*Images are shown for reference only, product specifications and data are subject to change without notice.
Confidence-inspiring handling and a rugged 223cc air-cooled, SOHC four-stroke producing predictable, broadband power make the TT-R230 a great choice for beginner and intermediate riders.
Smooth-shifting, six-speed transmission with heavy-duty clutch geared for maximum versatility and usable power delivery.
36mm front fork with 240mm of wheel travel provides plush, confidence inspiring control over rough terrain.
295mm of ground clearance should be enough to deal with almost any trail.
Lightweight exhaust has a quiet, approved muffler and spark arrestor.
Front 220mm disc and 130mm rear drum brakes for powerful, confident stops. Full-size 21-inch front and 18-inch rear aluminium wheels keep unsprung weight down, while knobby tires provide motocross-spec grip.
Electric start makes getting started a complete push button exercise.
A low seat height atop long-travel suspension and 295mm of ground clearance makes this a very capable trailbike suitable to a wide range of riders.
| Engine Type | Air-cooled, 4-stroke, SOHC, 2-valve |
| Displacement | 223 cc |
| Bore x Stroke | 70.0 x 58.0 mm |
| Compression Ratio | 9.5 : 1 |
| Lubrication System | Wet sump |
| Fuel Management | Y26P x 1 |
| Ignition | CDI |
| Starter System | Electric starter |
| Fuel Tank Capacity | 8 L |
| Oil Capacity | 1.3 L |
| Final Transmission | Chain |
| Transmission | Constant mesh 6-speed |
| Length | 2065 mm |
| Width | 800 mm |
| Height | 1180 mm |
| Seat Height | 870 mm |
| Wheelbase | 1385 mm |
| Ground Clearance | 295 mm |
| Dry Weight | 108 kg |
| Wet Weight | 114 kg with 8 litres of fuel |
| Frame Type | Diamond |
| Suspension Front | Telescopic forks, 240mm travel |
| Suspension Rear | Swingarm, 220mm travel |
| Brakes Front | Single 220mm disc |
| Brakes Rear | Drum |
| Tyres Front | 80/100-21 51R |
| Tyres Rear | 100/100-18 59R |
